Compact modern design
IP40 or IP65 front protection
Easy to mount
Continuous or intermittent tone
Reliable and proven technology
Specifications
| Rated Insulation Voltage | 30V DC |
| Rated Operating Voltage | 12V DC±10%、24 DC±10% |
| Current Draw | 40mA |
| Insulation Resistance | ≥100 MΩ |
| Sound Pressure(at0.1m) | Steady sound:80dB minium(at the rated voltage) |
| Operating Temperature | -25℃~+55℃（no freezing） |
| Storage Temperature | -40℃~+70℃（no freezing） |
| Operating Humdidty | 40~85%RH （no condensation) |
| 文件名称 | 类型 | 发布时间 | |
| AF16L Buzzer | 12/30/2024 | 下载(605.88 KB) |
